barcode, robotics and industrial lens

Finite Imaging

Our low-profile compact lenses are designed to provide high image quality with low distortion when the object distance is greater than about 10 times the focal length, or for on-axis imaging. They are applicable for finite object imaging applications such as face/object recognition, barcode readers, document imaging, machine vision, and biometric security.

We provide two online wizards to assist you to choose the right lens:

  • Imaging optics solver: Solves for the effective focal length (EFL) based on object and image size constraints. A good starting point for finite conjugate applications such as barcode scanning, etc.
  • Field of view or EFL calculator: Calculates FOV (in degree) of a lens on a given imager if the EFL is known, and vice vesa. This wizard factors into the geometric distortion of the lens.  Therefore, it is applicable to all lenses from telephoto to fisheye types.
  • List of off-the-shelf finite imaging lenses

Robotics Vision

Many of Sunex standard wide-angle and fisheye lenses are suitable for robotics vision applications.  For 3D applications we offer Boresight Stabilization – a proprietary technology eliminating lateral shift (Boresight) of the lens elements due to shock or vibration. This is especially critical in 3D imaging, where a shift of just a few pixels is often unacceptable.

Inspection

Sunex wide-angle and fisheye lenses are becoming increasingly popular in a variety of inspection application, such as boroscopes or pipe inspection.  Several factors make Sunex lenses ideal for this type of application. The low profile and small physical sizes of our lenses, combined with small sensor formats for which the lenses were designed, allow for very compact camera packaging. Moreover, our ability to customize provides you with a variety options to meet your unique requirements.

Customization Capabilities Include:

  • IP rated sealing

  • IR coatings with IR band-pass for Day/Night imaging (IRC40)

  • Hydro-phobic/phillic coatings

  • Relative aperture (F/#) modifications (calculate depth of field)

  • Mechanical barrel redesign

  • Boresight Stabilization

PN Description Focal length(mm) f/# Imager Format Field of view/
Depth of field
Recommended Holder Sample Price (1-99) Volume Price
DSL756A-NIR-F2.8 DISCONTINUED! Sold until out of inventory. Low-profile plastic lens for 1/4" sensor, NO IR cut-off, EFL=3.4, F/2.8, M7x0.35 3.8 2.8 1/4" Calculate FOV
Calculate DOF
CMT756, CMT756-IRC30 $69
Order Sample
Request Volume Quote
DSL871F-650-F2.8 Low profile hybrid lens with IR cut filter for 1/3.2" sensor, EFL=5.1, F/2.8, M8x0.35, metal barrel 5.1 2.8 1/3.2" Calculate FOV
Calculate DOF
CMT746, CMT951 $69
Order Sample
Request Volume Quote
DSL871F-NIR-F2.8 Low profile hybrid lens for 1/3.2" sensor, NO IR cut coating, EFL=5.1, F/2.8, M8x0.35, metal barrel 5.1 2.8 1/3.2" Calculate FOV
Calculate DOF
CMT746, CMT951 $69
Order Sample
Request Volume Quote
DSL871G-NIR-F2.8 Low profile hybrid lens for 1/3.2" sensor, NO IR cut coating, EFL=5.1, F/2.8, M12x0.5 5.1 2.8 1/3.2" Calculate FOV
Calculate DOF
  $69
Order Sample
Request Volume Quote
DSL944B-NIR-F2.8 Low-profile glass lens, no IR cutoff coating, for 1/2.5" sensor, EFL=7.5, F/2.8, M8x0.35, metal barrel 7.5 2.8 1/2.5" Calculate FOV
Calculate DOF
CMT233, CMT683 $69
Order Sample
Request Volume Quote
DSL944B-650-F2.8 Low-profile glass lens with IR cutoff coating for 1/2.5" sensor, EFL=7.5, F/2.8, M8x0.35, metal barrel 7.5 2.8 1/2.5" Calculate FOV
Calculate DOF
CMT233, CMT683 $69
Order Sample
Request Volume Quote
DSL944C-650-F2.8 Low-profile glass lens with IR cutoff coating for 1/2.5" sensor, EFL=7.5, F/2.8, M12x0.5, metal barrel 7.5 2.8 1/2.5" Calculate FOV
Calculate DOF
CMT821 $69
Order Sample
Request Volume Quote
DSL944C-NIR-F2.8 Low-profile glass lens, no IR cutoff coating, for 1/2.5" sensor, EFL=7.5, F/2.8, M12x0.5, metal barrel 7.5 2.8 1/2.5" Calculate FOV
Calculate DOF
CMT821 $69
Order Sample
Request Volume Quote
DSL944D-BP940-F2.8 Low-profile glass lens, with custom IR Bandpass filter centered at 940nm, for 1/2.5" sensor, EFL=7.5, F/2.8, M8x0.35, metal barrel 7.5 2.8 1/2.5" Calculate FOV
Calculate DOF
CMT821 $69
Order Sample
Request Volume Quote
DSL944D-950BP-F2.8 Low-profile glass lens, with updated IR Bandpass filter centered at 950nm, for 1/2.5" sensor, EFL=7.5, F/2.8, M8x0.35, metal barrel 7.5 2.8 1/2.5" Calculate FOV
Calculate DOF
CMT821 $69
Order Sample
Request Volume Quote
DSL934B-NIR-F3.0 Miniature multi-megapixel lens for 1/1.8" sensor, NO IR cut coating, EFL=9.0, F/3.0, M12x0.5, metal barrel 9 3 1/1.8" Calculate FOV
Calculate DOF
CMT821 $69
Order Sample
Request Volume Quote
DSL934C-670-BBAR-F3.0 Low-profile glass lens with IR cut coating at 670nm, high efficiency BBAR coating, EFL=9.0, F/3.0, M12x0.5, metal barrel with wrench flats 9 3 1/1.8" Calculate FOV
Calculate DOF
  $69
Order Sample
Request Volume Quote
DSL934A-650-F3.0 Miniature multi-megapixel lens with IR cut coating for 1/1.8" sensor, EFL=9.0, F/3.0, M10x0.35, metal barrel 9 3 1/1.8" Calculate FOV
Calculate DOF
CMT934 $69
Order Sample
Request Volume Quote
DSL934B-650-F3.0 Miniature multi-megapixel lens with IR cut coating for 1/1.8" sensor, EFL=9.0, F/3.0, M12x0.5, metal barrel 9 3 1/1.8" Calculate FOV
Calculate DOF
CMT821 $69
Order Sample
Request Volume Quote
DSL934C-670-BBAR-F2.5 Low-profile glass lens with IR cut coating at 670nm, high efficiency BBAR coating, EFL=9.0, F/2.5, M12x0.5, metal barrel with wrench flats 9 2.5 1/1.8" Calculate FOV
Calculate DOF
  $69
Order Sample
Request Volume Quote
DSL934C-670-BBAR-F2.0 Low-profile glass lens with IR cut coating at 670nm, high efficiency BBAR coating, EFL=9.0, F/2.0, M12x0.5, metal barrel with wrench flats 9 2 1/1.8" Calculate FOV
Calculate DOF
  $69
Order Sample
Request Volume Quote
DSL934A-NIR-F3.0 Miniature multi-megapixel lens with NO IR cut coating for 1/1.8" sensor, EFL=9.0, F/3.0, M10x0.35, metal barrel 9 3 1/1.8" Calculate FOV
Calculate DOF
CMT934 $69
Order Sample
Request Volume Quote
DSL935A-650-F3.0 Miniature multi-megapixel lens with IR cut coating for 1/1.8" sensor, EFL=9.6, F/3.0, M12x0.5, metal barrel 9.6 3 1/1.8" Calculate FOV
Calculate DOF
CMT107, CMT804 $69
Order Sample
Request Volume Quote
DSL935A-650-F2.5 Miniature multi-megapixel lens with IR cut coating for 1/1.8" sensor, EFL=9.6, F/2.5, M12x0.5, metal barrel 9.6 2.5 1/1.8" Calculate FOV
Calculate DOF
CMT107, CMT804 $69
Order Sample
Request Volume Quote
DSL935A-NIR-F3.0 Miniature multi-megapixel lens, NO IR cut coating, for 1/1.8" sensor, EFL=9.6, F/3.0, M12x0.5, metal barrel 9.6 3 1/1.8" Calculate FOV
Calculate DOF
CMT107, CMT804 $69
Order Sample
Request Volume Quote
[1/2]

Didn’t find the lens you’re looking for? Try searching our entire lens database using one of the following options:
