automotive emerging applications Emerging automotive vision encompasses those applications that will be vision based cameras but are still under development or test.  These applications might include vision-based driver awareness, occupant sensing or airbag control.  For these vision applications, Sunex is ready to support the demands of the application whether it requires designs optimized for the near-IR, passing only IR, single-wavelength, reflective surfaces� anything is possible.

Below is the list of our automotive lenses.  For this type of application it may be best to check our complete list of off-the-shelf lenses.  The off-the-shelf solutions are often a good starting point for a custom OEM solution.  If you do not see something that exactly meets your requirements, please contact us to discuss the possibilities:
PN Description Focal length(mm) f/# Imager
Format
Field of view/
Depth of field
Recommended Holder Sample Price (1-99) Volume Price
DSL188A-NIR-F2.0 Superfisheye, hybrid, for 1/4" sensors, HDR, 0.94mm EFL, 4.0mm image circle, F/2.0. Aluminum barrel threaded M12x0.5. IR Cut filter at 650nm. 0.94 2 1/4" Calculate FOV
Calculate DOF
  $59
Order Sample
Request Volume Quote
DSL188A-650-F2.0 Superfisheye, hybrid, for 1/4" sensors, HDR, 0.94mm EFL, 4.0mm image circle, F/2.0. Aluminum barrel threaded M12x0.5. IR Cut filter at 650nm. 0.94 2 1/4" Calculate FOV
Calculate DOF
  $59
Order Sample
Request Volume Quote
DSL180B-NIR-F2.0 Miniature tailored distortion fisheye lens, without IR cut filter, EFL=0.97mm, F/2.0, M12x0.5 slipfit, metal barrel. Compatible with CMT168. 0.97 2 1/4" Calculate FOV
Calculate DOF
CMT168-1122F $59
Order Sample
Request Volume Quote
DSL180A-690-F2.0 Miniature tailored distortion fisheye lens, with IR cut filter, EFL=0.97mm, F/2.0, M12x0.5, metal barrel. Compatible with CMT821. 0.97 2 1/4" Calculate FOV
Calculate DOF
CMT821, CMT002 $59
Order Sample
Request Volume Quote
DSL180A-NIR-F2.0 Miniature tailored distortion fisheye lens, without IR cut filter, EFL=0.97mm, F/2.0, M12x0.5, metal barrel. Compatible with CMT821. 0.97 2 1/4" Calculate FOV
Calculate DOF
CMT821, CMT002 $59
Order Sample
Request Volume Quote
DSL180B-690-F2.0 Miniature tailored distortion fisheye lens, with IR cut filter, EFL=0.97mm, F/2.0, M12x0.5 slipfit, metal barrel. Compatible with CMT168. 0.97 2 1/4" Calculate FOV
Calculate DOF
CMT168-1122F $59
Order Sample
Request Volume Quote
DSL367B-NIR-F2.1 Superfisheye, hybrid, for 1/4" sensors, HDR, 0.98mm EFL, 4.2mm image circle, 210° FOV, F/2.1. Aluminum barrel threaded M12x0.5. NO IR Cut filter. 0.98 2.1 1/4" Calculate FOV
Calculate DOF
  $59
Order Sample
Request Volume Quote
DSL367B-650-F2.1 Superfisheye, hybrid, for 1/4" sensors, HDR, 0.98mm EFL, 4.2mm image circle, 210° FOV, F/2.1. Aluminum barrel threaded M12x0.5. IR Cut filter at 650nm. 0.98 2.1 1/4" Calculate FOV
Calculate DOF
  $59
Order Sample
Request Volume Quote
DSL198A-650-F2.0 Superfisheye lens, HDR, 1.03mm EFL, 4.0mm image circle, 214deg FOV, F/2.0. Aluminum barrel threaded M12x0.5. IR Cut Filter at 650nm. 1.03 2 1/4" Calculate FOV
Calculate DOF
  $59
Order Sample
Request Volume Quote
DSL198A-NIR-F2.0 Superfisheye lens, HDR, 1.03mm EFL, 4.0mm image circle, 214deg FOV, F/2.0. Aluminum barrel threaded M12x0.5. NO IR Cut Filter. 1.03 2 1/4" Calculate FOV
Calculate DOF
  $59
Order Sample
Request Volume Quote
DSL218A-NIR-F2.0 Miniature super fisheye lens, no IR cut filter, EFL = 1.2mm, F/2.0, M12x0.5, metal barrel ***C-mount adapter available! CMT1205-C***. Distortion dewarping software available. 1.2 2 various Calculate FOV
Calculate DOF
CMT821, CMT002 $99
Order Sample
Request Volume Quote
DSL218A-670-F2.0 Miniature super fisheye lens, with IR cut filter, EFL = 1.2mm, F/2.0, M12x0.5, metal barrel ***C-mount adapter available! CMT1205-C***. Distortion dewarping software available. 1.2 2 various Calculate FOV
Calculate DOF
CMT821, CMT002 $99
Order Sample
Request Volume Quote
DSL236E-670-F2.0 Wide-angle hybrid lens for OV9715. EFL=1.23, F/2.0; Plastic barrel, aluminum cap; Decentration <1.0; Sealed; HP coating on L1-S1; Laser engraved PN, mark on retaining cap 1.23 2 1/4" Calculate FOV
Calculate DOF
  $59
Order Sample
Request Volume Quote
DSL181B-NIR-F2.2 Miniature tailored distortion fisheye lens, without IR cut filter, EFL=1.25mm, F/2.2, M12x0.5 slipfit, metal barrel. Compatible with CMT168. 1.25 2.2 1/3.2" Calculate FOV
Calculate DOF
CMT168-1122F $59
Order Sample
Request Volume Quote
DSL181C-650-F2.2 Superfisheye lens, Tailored Distortion, HDR, EFL=1.25mm, 190deg HFOV, F/2.2, 4.8mm image circle. Aluminum barrel threaded M12x0.5. IR Cutoff Filter at 650nm. 1.25 2.2 1/3.2" Calculate FOV
Calculate DOF
  $59
Order Sample
Request Volume Quote
DSL181B-650-F2.2 Miniature tailored distortion fisheye lens, with IR cut filter, EFL=1.25mm, F/2.2, M12x0.5 slipfit, metal barrel. Compatible with CMT168. 1.25 2.2 1/3.2" Calculate FOV
Calculate DOF
CMT168-1122F $59
Order Sample
Request Volume Quote
DSL216A-670-F2.8 Miniature super fisheye lens with IR cut coating, EFL = 1.3mm, F/2.8, M12x0.5, metal barrel, UV-anodize, sealed first element***C-mount adapter available! CMT1205-C***. Distortion dewarping software available. 1.26 2.8 various Calculate FOV
Calculate DOF
CMT821, CMT002 $99
Order Sample
Request Volume Quote
DSL216A-670-F2.0 Miniature super fisheye lens with IR cut coating, EFL = 1.3mm, F/2.0, M12x0.5, metal barrel ***C-mount adapter available! CMT1205-C***. Distortion dewarping software available. 1.26 2 various Calculate FOV
Calculate DOF
CMT821, CMT002 $99
Order Sample
Request Volume Quote
DSL266A-NIR-F1.8 Miniature super fisheye lens, with NIR cut filter, EFL-1.3mm, F1.8, M12x.5, Metal Barrel. Designed for 1/3" format sensors. Contains 12.2mm centering feature below lens flange. 1.27 1.8 1/4" Calculate FOV
Calculate DOF
CMT821, CMT168-11XX $99
Order Sample
Request Volume Quote
DSL266A-650-F1.8 Miniature super fisheye lens, with 650nm IR cut filter, EFL-1.3mm, F1.8, M12x.5, Metal Barrel. Designed for 1/3" format sensors. Contains 12.2mm centering feature below lens flange. 1.27 1.8 1/4" Calculate FOV
Calculate DOF
CMT821, CMT168-11XX $99
Order Sample
Request Volume Quote
[1/8]
