 Sunex
is a world leading provider of high quality lenses for automotive OEM and commercial
vehicle applications. As a qualified Tier 2 supplier we have
significant experience bringing leading edge products to
market. We are a pioneer in advanced optical technology such as
low-flare, low-ghost lenses suitable for WDR and HDR CMOS
imagers and miniature fisheye lenses, up to 200°
field of view; as well as Tailored Distortion®
lenses that reduce optical distortion.
For more than five years, Sunex has focused on
developing long-term partnerships and has built a
reputation as a trustworthy Tier 2 supplier. Today,
Sunex automotive lenses can be found in major brands around the world.
Designing and manufacturing lenses
for automotive vision applications presents significant challenges in
all phases of the product life-cycle, from concept to design,
manufacturing, and end-of-life. Sunex has developed proprietary
material and process know-how to meet those demands. As a Tier 1 customer of Sunex you
can expect to work directly with a US-based Sales
Manager and engineers that have a in-depth understanding
of the technical and
commercial expectations. Our US-based team is
supported by a team of engineers, quality assurance,
project management and logistics personnel based at Sunex Optics-Electronics Shanghai. Sunex China is ISO
9001:2000 and
ISO/TS 16949:2002 certified. Our team is
experienced with the necessary PPAP documentation,
project launch and capacity planning. Validation
testing can be performed both in-house and with several
qualified outside labs. Sunex has developed
proprietary test capabilities to ensure that all control points are met
during series production. We can support IMDS and
end-of-life requirements. Sunex is fully invested in the automotive market and
intends to be a long-term Tier 2 supplier. Please
contact our support
team with any further questions.
Search for automotive lenses by application:
| PN |
Description |
Focal length(mm) |
f/# |
Imager
Format |
Field of view/
Depth of field |
Recommended Holder
|
Sample Price (1-99) |
Volume Price |
 DSL221A-650-F2.0
|
Wide-angle hybrid lens with IR cut filter for 1/4" sensor, EFL=1.10mm, F/2.0, aluminum barrel threaded M12x0.5
|
1.1
|
2
|
1/4"
|
Calculate FOV
Calculate DOF |
CMT821 CMT002
|
$99
Order Sample |
Request Volume Quote |
| DSL218A-NIR-F2.0
|
C-mount adapter available! Miniature super fisheye lens, no IR cut filter, EFL = 1.2, F/2.0, M12x0.5, metal barrel ***C-mount adapter available! CMT1205-C***. Distortion dewarping software available.
|
1.2
|
2
|
various
|
Calculate FOV
Calculate DOF |
CMT821, CMT002
|
$99
Order Sample |
Request Volume Quote |
| DSL218A-670-F2.0
|
C-mount adapter available! Miniature super fisheye lens, with IR cut filter, EFL = 1.2, F/2.0, M12x0.5, metal barrel ***C-mount adapter available! CMT1205-C***. Distortion dewarping software available.
|
1.2
|
2
|
various
|
Calculate FOV
Calculate DOF |
CMT821, CMT002
|
$99
Order Sample |
Request Volume Quote |
| DSL216A-670-F2.0
|
C-mount adapter available! Miniature super fisheye lens with IR cut coating, EFL = 1.3, F/2.0, M12x0.5, metal barrel ***C-mount adapter available! CMT1205-C***. Distortion dewarping software available.
|
1.26
|
2
|
various
|
Calculate FOV
Calculate DOF |
CMT821, CMT002
|
$99
Order Sample |
Request Volume Quote |
| DSL217C-670-F1.8
|
C-mount adapter available! Miniature super fisheye lens, IR cut-off at 670nm, EFL = 1.3, F/1.8, M12x0.5, sealed IP6K9K, metal barrel ***C-mount adapter available! CMT1205-C***. Distortion dewarping software available.
|
1.3
|
1.8
|
various
|
Calculate FOV
Calculate DOF |
CMT821, CMT002
|
$99
Order Sample |
Request Volume Quote |
| DSL217C-NIR-F1.8
|
C-mount adapter available! Miniature super fisheye lens, no IR cut filter, EFL = 1.3, F/1.8, M12x0.5, sealed IP6K9K, metal barrel ***C-mount adapter available! CMT1205-C***. Distortion dewarping software available.
|
1.3
|
1.8
|
various
|
Calculate FOV
Calculate DOF |
CMT821, CMT002
|
$99
Order Sample |
Request Volume Quote |
| DSL215B-690-F2.0
|
C-mount adapter available! Miniature super fisheye lens with IR cut coating, EFL = 1.6, F/2.0, M12x0.5, metal barrel ***C-mount adapter available! CMT1205-C***. Distortion dewarping software available.
|
1.55
|
2
|
various
|
Calculate FOV
Calculate DOF |
CMT821, CMT002
|
$99
Order Sample |
Request Volume Quote |
| DSL209A-650-F2.0
|
Wide-angle glass lens with IR cut-off coating for 1/4" sensor, EFL=1.7, F/2.0, M12x0.5. Distortion dewarping software available.
|
1.7
|
2
|
1/4"
|
Calculate FOV
Calculate DOF |
CMT821, CMT804
|
$49
Order Sample |
Request Volume Quote |
| DSL219D-650-F2.0
|
Multi-megapixel miniature fisheye lens with IR cut coating, EFL = 1.8, F/2.0, M12x0.5, metal barrel ***C-mount adapter available! CMT1205-C***. Distortion dewarping software available.
|
1.8
|
2
|
1/2.5"
|
Calculate FOV
Calculate DOF |
CMT821, CMT002
|
$99
Order Sample |
Request Volume Quote |
| DSL212D-650-F3.0
|
Wide-angle glass lens for 1/3" sensor, with integrated IR cut-off filter, EFL=1.97, F/3.0, aluminum barrel threaded M12x0.5
|
1.97
|
3
|
1/3"
|
Calculate FOV
Calculate DOF |
CMT821, CMT002
|
$49
Order Sample |
Request Volume Quote |
| DSL212D-NIR-F3.0
|
Wide-angle glass lens for 1/3" sensor, NO IR cut-off filter, EFL=1.97, F/3.0, aluminum barrel threaded M12x0.5
|
1.97
|
3
|
1/3"
|
Calculate FOV
Calculate DOF |
CMT821, CMT002
|
$49
Order Sample |
Request Volume Quote |
| DSL224D-NIR-F2.0
|
Wide-angle glass lens for 1/3" sensor, NO IR cut-off filter, EFL=1.97, F/2.0, aluminum barrel threaded M12x0.5
|
2.16
|
2
|
1/3"
|
Calculate FOV
Calculate DOF |
CMT821, CMT002
|
$49
Order Sample |
Request Volume Quote |
| DSL224D-650-F2.0
|
Wide-angle glass lens for 1/3" sensor, with integrated IR cut-off filter, EFL=1.97, F/2.0, aluminum barrel threaded M12x0.5
|
2.16
|
2
|
1/3"
|
Calculate FOV
Calculate DOF |
CMT821, CMT002
|
$49
Order Sample |
Request Volume Quote |
| DSL202A-650-F2.8
|
Wide-angle glass lens with IR cut coating for 1/3" sensor, EFL=3.9, F/2.8, M12X0.5, metal barrel
|
3.9
|
2.8
|
1/3"
|
Calculate FOV
Calculate DOF |
CMT107, CMT103 CMT804
|
$49
Order Sample |
Request Volume Quote |
| DSL958E-700-F1.7
|
Wide-angle, low distortion lens for forward machine vision, IR cut-off at 700nm, EFL=4.6, F/1.7, aluminum barrel, threaded M10X0.5
|
4.6
|
1.7
|
1/3"
|
Calculate FOV
Calculate DOF |
CMT830, CMT685
|
$49
Order Sample |
Request Volume Quote |
| DSL958G-NIR-F1.7
|
Wide-angle, low distortion lens for forward machine vision, NO IR cut, EFL=4.6, F/1.7, aluminum barrel, threaded M12X0.5
|
4.6
|
1.7
|
1/3"
|
Calculate FOV
Calculate DOF |
CMT821, CMT107, CMT804
|
$49
Order Sample |
Request Volume Quote |
| DSL958G-700-F1.7
|
Wide-angle, low distortion lens for forward machine vision, IR cut-off at 700nm, EFL=4.6, F/1.7, aluminum barrel, threaded M12X0.5
|
4.6
|
1.7
|
1/3"
|
Calculate FOV
Calculate DOF |
CMT821, CMT107, CMT804
|
$49
Order Sample |
Request Volume Quote |
| DSL958E-NIR-F1.7
|
Wide-angle, low distortion lens for forward machine vision, no IR filter, EFL=4.6, F/1.7, aluminum barrel, threaded M10X0.5
|
4.6
|
1.7
|
1/3"
|
Calculate FOV
Calculate DOF |
CMT830, CMT685
|
$49
Order Sample |
Request Volume Quote |
| DSL819B-650-F2.8
|
Low-profile glass lens with IR cut coating for 1/3.4" sensor, EFL=5.1, F/2.8, M8x0.5, metal barrel
|
5.1
|
2.8
|
1/3.4"
|
Calculate FOV
Calculate DOF |
CMT830
|
$49
Order Sample |
Request Volume Quote |
| DSL946C-NIR-F1.6
|
Low stray light lens for High or Wide Dynamic Range, NO IR cut, EFL=5.7, F/1.6, metal barrel threaded M12x0.5
|
5.7
|
1.6
|
1/3"
|
Calculate FOV
Calculate DOF |
CMT830, CMT685
|
$49
Order Sample |
Request Volume Quote |
|
Didn’t find the lens you’re looking for? Try searching our
entire lens database using one of the following options:
|
